ماسفت قدرت FMH13N60S1 نوع N-Channel ژاپنی مارک FUJI پکیج TO-3P

Specification

Type Designator: FMH13N60S1
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Maximum Power Dissipation (Pd): 105 W
Maximum Drain-Source Voltage |Vds|: 600 V
Maximum Gate-Source Voltage |Vgs|: 30 V
Maximum Gate-Threshold Voltage |Vgs(th)|: 3.5 V
Maximum Drain Current |Id|: 13 A
Maximum Junction Temperature (Tj): 150 °C
Total Gate Charge (Qg): 35 nC
Rise Time (tr): 38 nS
Drain-Source Capacitance (Cd): 70 pF
Maximum Drain-Source On-State Resistance (Rds): 0.28 Ohm
